Vacuum Defoamer SIE‑ZK1000


Kiloliter‑Grade Extra‑Large Chamber · Batch Defoaming for Whole Oversized Workpieces

1000L Chamber for Whole Oversized Workpieces + Customizable Multi‑Layer Mesh Plates for Parallel Batch Processing + Multi‑Point Temperature Control Ensures Uniform Chamber Temperature

SIENOX SIE‑ZK1000 vacuum defoamer adopts a 1000L kiloliter‑grade chamber of 1000×1000×1000mm for whole‑piece defoaming of oversized workpieces. Layers and layer spacing of multi‑layer mesh plates are customizable. Multi‑point temperature sensors guarantee uniform temperature inside the large chamber. Multi‑segment PID temperature control ranges from ambient to 300℃ with accuracy of ±0.5℃. Non‑contact vacuum defoaming keeps material chemical properties unchanged.

✓ CE Certification  ✓ FC Certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Customizable Voltage (110V/220V)

Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Must Microbubbles in Materials Be Eliminated?

Residual micro‑bubbles degrade end‑product quality directly

Transformer Potting Industry

Extra‑large transformers and high‑voltage power devices feature large potting volume and abundant bubbles. Voids in cured insulation may trigger partial discharge or breakdown. The 1000L kiloliter‑grade vacuum defoaming chamber accepts whole‑unit loading to complete defoaming in one run. Auxiliary heating reduces potting compound viscosity for full escape of deep‑layer bubbles and ensures insulation reliability of extra‑large transformers.

Resin Craft Industry

Internal bubbles are hard to eliminate for monolithic oversized resin sculptures. Conventional chambers cannot accommodate such workpieces, while splitting brings extra procedures and re‑bubble risks. The 1000L large chamber enables whole‑piece defoaming without splitting. Heating lowers resin viscosity to release deep‑layer bubbles for smooth surface and compact interior of oversized artworks.

Silicone Rubber Industry

Bubbles during casting of large silicone rubber parts and industrial seals cause sealing defects and degraded physical properties. Stable defoaming is essential for mass‑production consistency. Customizable multi‑layer mesh plates support parallel batch processing. Automatic constant‑pressure cycle sustains long‑time defoaming. The 1000L chamber processes large‑volume workpieces per batch for higher throughput and consistent defoaming performance.

✨ Dilemmas of traditional solutions: Oversized products cannot fit into standard‑size chambers and have to be split, adding procedures and re‑bubble risks. Insufficient equipment capacity for mass production causes repeated batching, queuing and delayed delivery. Uneven temperature inside large chambers leads to inconsistent defoaming results across positions and poor batch repeatability.

Why Choose SIE‑ZK1000

Solve capacity‑consistency pain points for oversized‑mass defoaming

1000L Chamber

Enables whole-piece defoaming for oversized products without splitting. Ideal for extra-large transformers, large resin sculptures, large battery modules and other oversized workpieces to finish defoaming in one time, avoiding secondary bubbles and extra processes caused by splitting treatment.

Multi-layer Mesh Plates for Parallel Batch Processing

Equipped with 2 layers and 2 mesh plates as standard, customizable up to 3-4 layers for mass production of small and medium-sized products. The layer spacing is adjustable to fit products of different heights. One machine for multiple uses, supporting whole-piece treatment for oversized items and multi-layer batch processing for small and medium workpieces, greatly boosting production capacity and meeting diverse mass production demands.

Multi-point Temperature Control for Uniformity

The large chamber is equipped with multi-point temperature sensors to monitor temperature in all areas in real time, adopting PID+SSR solid state relay temperature control with an accuracy of ±0.5℃. Precise temperature control ensures consistent defoaming effect for products in different positions and stable batch production quality.

✨ If you need to process oversized workpieces, high‑volume mass production, or require uniform temperature within large chambers, ZK1000’s kiloliter‑grade chamber and multi‑layer parallel design can meet your large‑scale demands.

Working Principle

Bubbles expand and burst under negative‑pressure environment to force gas escape and improve material compactness.

Step 1: Vacuumize to build negative pressure
Built‑in vacuum pump reaches ‑100kPa within 3‑5 minutes. Negative pressure expands bubbles inside materials.

Step 2: Heating‑assisted defoaming
Thermal radiation heating adjustable from ambient to 300℃ reduces material viscosity and accelerates bubble rupture and escape.

Step 3: Non‑contact property preservation
Materials stand still inside vacuum chamber without agitator contact, keeping original chemical properties.


Three simple steps: Vacuumizing → Heating Assistance → Non‑contact Preservation to improve material compactness.

Vacuum Defoamer Working Principle.jpg

Technical Specifications

Complete Technical Specifications Overview, Customizable on Demand

ModelSIE-ZK1000
Chamber Dimension1000×1000×1000mm* Larger volume customizable
Effective Volume1000L
Cabinet StructureIntegrated unit with built‑in vacuum pump
Temperature RangeAmbient+30~300℃
Safety ProtectionOver‑temperature protection, overload protection, ground protection
Vacuum Degree0~‑100kPa
Internal Shelves2 inner layers with 2 mesh plates (3‑4 layers customizable)
Power Supply380V220V, 50/60Hz
Overall Dimension(W×D×H)Approx.1400×1380×2230mm (with casters, subject to actual product)
Net WeightApprox. 30 kg
Certifications CE, FC, ISO9001, RoHS Compliance

Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • 脱泡机的作用是什么?

    脱泡机是一种用于去除液体中的气泡的设备。它的作用在于帮助生产过程中的液体混合、反应、涂布、印刷、灌注等工艺环节,避免气泡的产生和对最终产品的影响。在许多工业和实验室环境中,去除气泡是非常必要的,因为气泡可能会对产品质量产生负面影响,如影响表面张力和稳定性等问题。脱泡机通常采用各种不同的技术,如振动、超声波、离心等,以实现有效的气泡去除。它的应用领域广泛,包括但不限于半导体、太阳能、光学、生物技术、材料科学等。

  • 售后服务怎么样?

    公司拥有专业的售后服务人员,24小时专人服务,一对一提供技术支持,解决您的后顾之忧。

  • 为什么要选择施诺斯?

    选择施诺斯的原因有很多,以下是一些主要的原因:

     1. 专业性:我们的团队由一群专业的人士组成,他们在各自的领域拥有丰富的经验和知识。我们不仅了解行业趋势和最佳实践,而且还能提供切实可行的解决方案。

     2. 服务质量:我们注重客户的需求和满意度,始终致力于提供高质量的服务。我们不仅快速响应客户需求,而且还能根据客户的要求进行定制化服务。

    3. 可靠性:我们以诚信和专业精神为宗旨,始终遵守承诺和协议。我们的工作方法和交付成果均符合行业标准和最佳实践,使得我们的客户能够信任我们。

    4. 创新性:我们不断探索新的方法和工具,以提供更好的服务并满足客户的需求。我们鼓励创新和实验,并愿意接受挑战和改变。

    5. 成本效益:我们提供高性价比的服务,不仅能够帮助客户节省成本,而且还能提高效率和生产力。我们始终以客户的利益为出发点,为客户提供最优的解决方案。

     6. 团队合作:我们相信团队的力量和合作的价值,我们的团队成员之间互相支持、协作和尊重。我们与客户、合作伙伴和其他利益相关者建立紧密的合作关系,以实现共同的目标。

    以上只是选择我们的部分原因,我们相信还有很多其他的优点和价值可以为客户提供。如果您正在寻找一家专业、可靠、高质量的服务提供商,我们非常期待与您的合作。

  • 搅拌脱泡机的工作原理?

    施诺斯搅拌脱泡机通过公转的离心力进行脱泡,通过公转与自转形成的剪切力进行搅拌,

    再辅助以真空泵抽取气体以达到真空状态,去除纳米级微小气泡。 不接触物料,无二次污染,无二次浪费。


  • 施诺斯能提供工程咨询技术服务吗?

    施诺斯能为广大客户提供全面的工程和现代化的咨询服务。施诺斯近二十年的搅拌经验,可以为你提供高效的咨询服务。

    想要让搅拌机性能更上一层楼,提升系统的整体效能?我们有全面的咨询、工程以及现代化改造服务,为您量身打造解决方案。 在如今竞争激烈的全球化浪潮中,唯有不断创新、持续优化,才能始终跑在对手前面。您的生产工艺和产品日新月异,我们就为您提供最适配的混合技术。不管是新的产品参数,还是既有的工艺条件,我们都能对现有系统和搅拌设备进行全方位的检查与评估,挖掘其中潜藏的流程优化空间和机械性能提升潜力,并且帮您把这些改进切实落地。 要是您的搅拌设备已经跟不上时代步伐,能耗居高不下,或是维护成本让您头疼不已,那就别犹豫,我们的咨询、工程设计和现代化改造服务,就是为您排忧解难的良方。欢迎随时联系我们,携手开启高效生产新征程!

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

ModelSIE-ZK400SIE-ZK500SIE-ZK1000
Chamber Dimension400×400×450mm500×500×500mm1000×1000×1000mm
Effective Volume72L125L1000L
Temperature RangeAmbient+30~300℃Ambient+30~300℃Ambient+30~300℃
Vacuum Degree0~-100kPa0~-100kPa0~-100kPa
Safety ProtectionOver‑temperature protection, overload protection, ground protectionOver‑temperature protection, overload protection, ground protectionOver‑temperature protection, overload protection, ground protection
Power Supply380V220V, 50/60Hz380V220V, 50/60Hz380V220V, 50/60Hz
Overall Dimension(W×D×H)510 × 430 × 500 mm610 × 560 × 780 mm1400×1380×2230mm
Net Weight95 kg153 kg153 kg
CertificationsCE, FCCE, FCCE, FC

*** Above are typical models. SIENOX provides customized solutions upon customer requirements. For model selection: 189‑2512‑9293

Multi‑Industry Solutions

Vacuum defoaming applications covering typical materials across six major industries


LED Consumer Electronics

LED epoxy resin, phosphor powder, UV adhesive


Cosmetics & Makeup

Cosmetic paste, lotion, gel


Laboratory & New Material R&D

Reagents, nano‑dispersion, polymer samples


Hardware & Plastics

Plastic potting adhesive, metal coating


Chemical Coatings

Color paste, printing ink


Pharmaceuticals

Pharmaceutical gel, diagnostic reagents

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Actual‑test Performance Demonstration

Lab Sample Actual Test Results

Lubricant Mixing & Defoaming.jpg

Paste‑like Materials

Photoresist Mixing & Defoaming.jpg

Adhesive & Powder

Polymer Materials.jpg

Polymer Materials

Gel Defoaming 02.jpg

Pharmaceutical Gel

Silver Paste Mixing & Defoaming.jpg

Silver Paste Materials

Battery Slurry Mixing & Defoaming 03.jpg

Battery Slurry

Measured Data Comparison

Material Defoaming Effect Comparison (Before & After)

Material Type
Status Before Treatment
After ZK1000 Treatment
Transformer Potting CompoundDense bubbles inside compound, large‑area voids appear in insulation layer after integral pottingDense compound without voids, stable insulation performance for integral potting
Epoxy ResinDense bubbles inside resin, pores exist both on surface and interior after integral castingClear and transparent resin, smooth surface and compact interior after integral casting
Silicone Rubber ProductsPlenty of bubbles inside silicone, large‑area defects on sealing surfaceUniform and compact silicone, reliable sealing performance

* Internal laboratory test data. Actual improvement varies with material formula. Contact sales for real‑world customer cases.
