Why You Need to Remove Bubbles

Trapped gas in industrial fluids is a manufacturing risk that compounds across the production chain.

Adhesion failure — Voids at bond interfaces weaken peel and shear strength, compromising structural integrity.

Performance degradation — In fillers and thermal interface materials, bubbles create hot spots and reduce thermal conductivity.

Surface defects — Pinholes and craters degrade product aesthetics and functional reliability.

Process inconsistency — Entrapped air causes skipped dots, tailing, and volume variation in automated dispensing.

Material waste — Batch rejection from bubble-related defects drives up cost and cycle time.

Bubble elimination is a prerequisite — not an optimization — for high-yield manufacturing.

Why SIE-MIX90

The SIE-MIX90 is a floor-standing vacuum centrifugal mixer purpose-built for laboratories, pilot lines, and small-to-medium batch production. Its balanced capacity, fixed-ratio repeatability, and wide material adaptability make it the go-to workhorse across multiple industries — from semiconductor encapsulants to battery slurries, solder pastes to cosmetic creams.

0–2000 RPM adjustable speed Broad process window adapts to low-viscosity inks through high-density pastes like solder paste and silver-filled adhesives.

Vacuum up to -98 kPa (‑100 kPa optional) Removes macro to nano‑scale bubbles; delivers 99.9% bubble elimination efficiency.

Non‑contact planetary mixing Zero blades, zero friction — no heat generation, no cross‑contamination. Material properties remain 100% intact.

Fixed revolution/rotation speed ratio Guarantees batch‑to‑batch repeatability — critical for process validation and quality documentation.

100‑program digital memory Operator‑independent recipes; store and recall validated parameters for consistent results across shifts.

Optional heating / cooling / MES Temperature‑controlled processing for heat‑sensitive formulations; full in‑line integration with real‑time traceability.

304 stainless steel, imported components Rugged 150 kg build for reliable daily use in industrial and lab environments.

CE, ISO9001, RoHS certified Global compliance for deployment across regulated industries.

Key differentiation — why MIX90 sits at the sweet spot: The MIX60 is a compact benchtop unit for R&D small batches (0–300 mL). The MIX80 bridges lab and pilot needs (0–300 mL, floor-standing). The MIX1000PLUS offers independently adjustable rotation ratios for high-viscosity process flexibility. The MIX90 fills the 0–1000 mL production bracket with a fixed-ratio design optimized for standardized workflows and multi-material versatility.

Working principle

By using the centrifugal force of revolution and the shear force of rotation to stir, coupled with a vacuum pump to extract gas, small bubbles in the liquid can be efficiently removed, improving product quality.

Product parameters table

***The above are just typical models, and we can provide personalized solutions according to customer needs.

Applications — Multi-Industry Versatility

The SIE-MIX90 processes materials from low-viscosity liquids to high-density pastes: solder paste, silver paste, aluminum paste, conductive silver adhesive, insulating adhesives, phosphor powders, silicone gel, potting compounds, battery electrode slurries, inks, silver nanowire dispersions, cosmetic creams, and pharmaceutical formulations.

Semiconductor & Electronics — Void‑free underfill, die‑attach adhesives, conductive paste processing. SIENOX technology achieves void rates below 0.001% and filler distribution uniformity of 99.2%.

New Energy & Battery — Electrode slurry homogenization; uniform conductive agent dispersion for consistent coating quality and improved cell cycle life.

LED & Optical Materials — Bubble‑free phosphor encapsulation for stable optical output and reduced chip failure rates.

Adhesives & Sealants — Epoxies, polyurethanes, MS polymers, structural glues — uniform filler dispersion without sedimentation.

Medical & Pharma — Contamination‑free processing of medical‑grade silicones and composites.

Cosmetics & Daily Chemicals — Creams and gels with smooth, air‑free texture; improved product stability and consumer appeal.

R&D Labs & Pilot Lines — Formulation development scaling seamlessly to small‑lot production.

SIENOX has accumulated 1,800+ material processing cases. Customers are welcome to bring their own materials for sample testing and machine trials.

Our cooperative clients

***Only partial successful customer information is displayed. We need more case studies and product selection materials. Please feel free to contact us

FAQ

1. What materials can the MIX90 process?

Solder paste, silver paste, aluminum paste, conductive silver adhesive, insulating adhesives, phosphor powders, silicone gel, battery electrode slurries, inks, silver nanowire dispersions, cosmetic creams, and pharmaceutical formulations. Free sample testing is available.

2. Does the process change material properties?

No. The non‑contact, bladeless design means zero friction, zero contamination, and zero alteration of chemical composition.

3. What containers are supported?

Standard cups (up to 1000 mL), tubes, cans, and fully custom proprietary containers. Single‑cup and dual‑cup configurations are available.

4. What is the difference between fixed and adjustable speed ratio?

Fixed ratio — as on the MIX60, MIX80, and MIX90 — is optimized for process repeatability and standardization. Adjustable ratio — as on the MIXF1000 — offers greater process flexibility for complex formulations. Contact us for guidance on the right model for your needs.

5. Can the MIX90 integrate into our production line?

Yes. Optional MES connectivity enables real‑time process data logging, recipe management, production tracking, and quality control traceability. Heating and cooling modules support temperature‑controlled processing.

6. How does the MIX90 differ from the MIX60, MIX80, and MIX1000PLUS?

The MIX60 is a benchtop R&D unit (0–300 mL, 3000 RPM). The MIX80 is a floor-standing lab-to-pilot unit (0–300 mL, 3000 RPM). The MIX90 is a floor-standing production unit with larger capacity (0–1000 mL, 2000 RPM). The MIX1000PLUS adds independently adjustable rotation ratios for high‑viscosity process flexibility.

7. How do I start a sample evaluation?

Send your materials to SIENOX — we provide free sample testing and a detailed process recommendation report tailored to your application.

 Sienox Defoaming Machine Product Selection Table

***The above are just typical models, and we can provide personalized solutions according to customer needs.

◆ Single cup/Dual cup options available

◆ Vacuum level up to -99kPa

◆ Can store up to 100 sets of operating parameters

◆ Multiple container options: tubes, tanks, and cups

◆ Non-contact design, does not alter the chemical properties of materials

◆ Planetary to rotation speed ratio options (fixed/adjustable)

◆ 0-2500RPM, adjustable for experimentation based on material characteristics

◆ High-speed mixing and defoaming in 1 minute, uniform mixing, eliminates nano-sized bubbles

◆ Customizable capacity, standard configurations include 300mL, 500mL, 1L, 2L, 5L, and 12L

◆ Uses imported components, body made of 304 stainless steel, durable and long-lasting

◆ Vacuum/Temperature control/MES system connectivity options available

◆ Aesthetically pleasing design, durable and robust

The vacuum defoaming mixer meets the mixing and defoaming needs for volumes ranging from 0 to 200 mL. Its adjustable planetary to rotational motion ensures clean and efficient mixing and defoaming. Customized services are offered to meet the diverse requirements of different customers. With a wide range of applications, the machine is aesthetically pleasing, durable, and robust.
