Resin Degasser

TEL:18925129293

Unsaturated Polyester Resin Defoaming Machine


Eliminate Air Entrapment in Unsaturated Polyester Casting · Reduce Pinholes and Interlayer Bubbles for Dense & Smooth Cast Surfaces

Pre-mixing of Powders + Vacuum Mixing & Defoaming + Efficient Casting Before Curing

SIENOX unsaturated polyester defoaming solution addresses trapped air in filled resin systems such as FRP, cast crafts and artificial stone during batching and curing. It adopts vacuum mixing and defoaming after powder pre-mixing to remove bubbles formed when blending resin and fillers, yielding products with dense surfaces and fewer pinholes and interlayer voids.

✓ CE Certification  ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Custom Voltage Available (110V/220V)

Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Unsaturated Polyester Defoaming Machine Is Required

FRP Industry

Hand lay-up and cast FRP parts often incorporate calcium powder, aluminum powder and glass fibers. Severe air entrapment during mixing creates interlayer bubbles and voids after curing, reducing product strength and corrosion resistance.

Resin Craft Industry

Cast crafts, ornaments and artificial stone demand high surface quality. Bubbles after curing lead to pinholes and pits, which hinder polishing and painting and lower the yield rate.

Coating & Anti-corrosion Industry

Unsaturated polyester coatings and anti-corrosion layers release heat rapidly during curing. Trapped air forms pinholes on coating surfaces, impairing protection performance and appearance.

✨ Traditional Dilemma: More stirring after powder addition brings more trapped air, resulting in dense pinholes on the surface after curing which cannot be eliminated even by polishing. Conventional vacuum chambers cannot handle high-filler systems. Vacuum mixing and defoaming after powder pre-mixing is therefore required.

Why Choose SIENOX UPR Defoaming Solution

Powder Pre-mixing & Degassing

Resin and fillers are pre-blended first and then mixed under vacuum to break up powder agglomerates and significantly reduce trapped air.

Efficient Casting Connection

Mixing and defoaming are completed in one vacuum mixing cycle. Casting is carried out within the exothermic curing window to reduce pinholes and interlayer bubbles.

Scalable & Reproducible

Smooth process scaling from lab-scale C/ZK series to mass-production MIX1000plus. Non-contact operation keeps resin ratio unchanged.

✨ The MIX60 integrates three core capabilities: deep vacuum defoaming, precision small sample processing, and reproducible process parameters. It is an ideal device for laboratory R&D scenarios requiring vacuum-assisted defoaming.

Equipment Supporting Description

Supporting Process Chain of Equipment

Pre-mixing resin and powder → Vacuum mixing and defoaming → Adding curing agent / accelerator → Casting / Vacuum bag molding.

Mixing and Defoaming Working Principle 03.jpg

Specifications & Parameters

Selection Guide

UPR ApplicationTypical ViscosityRecommended Defoaming MethodRecommended Equipment
Small Sample Batching for CraftsLow - Medium ViscosityCentrifugal / Vacuum DefoamingC Series / ZK Series
Mixing of Filled ResinMedium - High ViscosityVacuum Mixing & DefoamingMIX Series / MIX1000plus
Vacuum Casting for FRPMedium ViscosityVacuum Mixing + Vacuum CastingMIX1000plus
High-transparency / High-density PartsLow - Medium ViscosityVacuum Mixing + Pressurized Fine DefoamingMIX1000plus / RX Series

Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • What is the working principle of a centrifugal defoaming machine?

    Principle of centrifugal defoaming machine: The bubbles are released by the downward principle of gravity.

  • How is the after-sales service?

    The company has professional after-sales service personnel, 24-hour dedicated service, and one-on-one technical support to solve your worries.

  • Why choose SIENOX?

    There are many reasons for choosing SIENOX, and the following are some of the main reasons:

    1. Professionalism: Our team consists of a group of professional individuals with rich experience and knowledge in their respective fields. We not only understand industry trends and best practices, but also provide practical and feasible solutions.

    2. Service quality: We focus on customer needs and satisfaction, and are always committed to providing high-quality services. We not only respond quickly to customer needs, but also provide customized services according to their requirements.

    3. Reliability: We adhere to the principles of integrity and professionalism, always adhering to commitments and agreements. Our work methods and deliverables comply with industry standards and best practices, enabling our clients to trust us.

    4. Innovation: We continuously explore new methods and tools to provide better services and meet customer needs. We encourage innovation and experimentation, and are willing to accept challenges and change.

    5. Cost effectiveness: We provide cost-effective services that not only help customers save costs, but also improve efficiency and productivity. We always prioritize the interests of our customers and provide them with the best solutions.

    6. Teamwork: We believe in the power and value of teamwork, and our team members support, collaborate, and respect each other. We establish close cooperative relationships with customers, partners, and other stakeholders to achieve common goals.

    The above are just some of the reasons for choosing us. We believe there are many other advantages and values that can be provided to customers. If you are looking for a professional, reliable, and high-quality service provider, we look forward to working with you.


  • How does the stirring and defoaming machine work?

    The SIENOX stirring and defoaming machine performs defoaming through centrifugal force at revolution and stirring through shear force formed by revolution and rotation,

    Assisted by a vacuum pump to extract gas and achieve a vacuum state, removing nanoscale tiny bubbles. No contact with materials, no secondary pollution, and no secondary waste.

  • What is the function of a defoaming machine?

    A defoaming machine is a device used to remove bubbles from liquids. Its function is to assist in the liquid mixing, reaction, coating, printing, infusion and other process steps in the production process, avoiding the generation of bubbles and their impact on the final product. In many industrial and laboratory environments, removing bubbles is essential as they may have a negative impact on product quality, such as affecting surface tension and stability. Defoaming machines typically use various techniques such as vibration, ultrasound, centrifugation, etc. to achieve effective bubble removal. It has a wide range of applications, including but not limited to semiconductors, solar energy, optics, biotechnology, materials science, etc.

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

UPR ApplicationTypical ViscosityRecommended Defoaming MethodRecommended Equipment
Small Sample Batching for CraftsLow - Medium ViscosityCentrifugal / Vacuum DefoamingC Series / ZK Series
Mixing of Filled ResinMedium - High ViscosityVacuum Mixing & DefoamingMIX Series / MIX1000plus
Vacuum Casting for FRPMedium ViscosityVacuum Mixing + Vacuum CastingMIX1000plus
High-transparency / High-density PartsLow - Medium ViscosityVacuum Mixing + Pressurized Fine DefoamingMIX1000plus / RX Series

Multi‑Industry Solutions

Covering stirring and debubbling applications of typical materials across six major industries


FRP

Pipes, storage tanks, gratings, vehicle body components

Resin Crafts.jpg

Resin Crafts

Ornaments, sculptures, cast decorative parts

Artificial Stone.jpg

Artificial Stone

Countertops, decorative panels, quartz stone formulations

Anti-corrosion Coatings.jpg

Anti-corrosion Coatings

Anti-corrosion floorings, linings, corrosion-resistant coatings

Button Products.jpg

Cast Products

Buttons, handles, small cast parts

Furniture Coatings.jpg

Furniture Coatings

PU/UP topcoats, wood coatings, putties

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Measured Defoaming‑Process Performance

Measured Processing Results for Six Typical Materials

Lubricant Mixing & Defoaming.jpg

Paste Materials

Adhesive + Powder Mixing & Defoaming.jpg

Adhesives + Powders

Polymer Materials.jpg

Polymer Materials

Gel Defoaming 02.jpg

Pharmaceutical Gels

Silver Paste Mixing & Defoaming.jpg

Silver Paste Materials

Battery Slurry & Adhesive Mixing & Defoaming.jpg

Battery Slurries



Precautions for Use

PrecautionsOperating Instructions
Feeding SequencePre-mix resin and powder first, then add curing agent / accelerator before defoaming and casting. Pay attention to ratio and sequence.
Heating for Viscosity ReductionFilled resin has high viscosity. Vacuum mixing with moderate heating is recommended to improve defoaming efficiency.
Prompt CastingCuring releases heat rapidly. Complete casting immediately after defoaming to avoid insufficient pot life.
Ventilation & Fire PreventionStyrene is volatile. Ensure adequate ventilation and fire protection during defoaming and casting.

* Internal laboratory test data. Actual results vary with material formulation and process. Contact sales for real customer cases.

Customer Delivery & Application Cases

Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.



Stirring‑Defoaming Solution for Glue Materials in Consumer‑Electronics Industry



Vacuum Defoaming Solution for Consumer Electronics Adhesives



Industrial University Solves Bubble Challenges of Coating‑Film Materials with SIENOX Defoaming Machine
