Vacuum Defoaming Mixer
TEL:18925129293
SIENOX Planetary Vacuum Mixing‑Defoaming Machine SIE‑MIX650
Vacuum Mixer‑Defoamer · Nano‑scale Bubble Removal
500mL Medium‑capacity Dual‑cup + Built‑in Maintenance‑free Vacuum — 99.9% Nano‑scale Bubble Removal
SIE‑MIX650 vacuum mixing‑defoaming machine meets 0‑500 mL mixing and defoaming requirements. Built‑in maintenance‑free vacuum unit combined with revolution‑rotation dual‑power mixing‑defoaming delivers consistent density, uniform dispersion and pure defoaming for multi‑material processing. Suitable for epoxy resin, conductive adhesive, electronic slurry, glue, gel and other materials. Customization available with one‑stop solutions provided.
✓ CE Certification ✓ FC Certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Customizable Voltage (110V/220V)
Why Must Microbubbles in Materials Be Eliminated?
Residual micro‑bubbles in materials directly affect finished‑product yield and performance
Electronics IndustryBubbles in potting adhesives cause cavities and gaps after electronic component encapsulation, impairing heat dissipation and insulation reliability. Bubbles in conductive silver paste lead to circuit breaks and resistance fluctuation. Bubbles in circuit‑board laminating adhesives produce bonding‑interface defects and reduce product yield. Medium‑to‑high‑viscosity adhesives tend to entrap air during conventional stirring, with slow natural bubble release and inconsistent encapsulation quality. | Medical Device IndustryBubbles in medical adhesives weaken bonding strength and biocompatibility. Bubbles in catheter & sensor potting adhesives trigger seal failure and signal interference. Bubbles in in‑vitro diagnostic reagent carriers compromise test accuracy. Medical devices demand high material purity; residual bubbles may cause batch‑to‑batch performance variation and raise quality risks. | Aerospace & Defense IndustryBubbles in composite matrix resins degrade interlaminar shear strength and fatigue resistance. Bubbles in structural adhesives induce stress concentration at bonding interfaces and harm long‑term reliability. Bubbles in radar‑absorbing coatings alter electromagnetic parameters. The aerospace sector allows minimal internal material defects; micro‑bubble residues may trigger structural‑part failure under extreme operating conditions. |
✨ Traditional defoaming challenges: Manual stirring or conventional impeller stirring actively entraps air and generates more bubbles with agitation. Static defoaming takes long time and delivers limited performance for high‑viscosity materials. Conventional vacuum defoaming only removes surface bubbles and fails to eliminate internal micro‑bubbles. The planetary mixing‑defoaming solution separates bubbles while mixing via centrifugal force, enhanced by negative‑pressure vacuum for deep defoaming to realize one‑step mixing and bubble removal.
Why Choose MIX650
Three Core Features Cover Full‑process Requirements for Medium‑capacity Vacuum Defoaming
Built‑in Maintenance‑free Vacuum for Clean DefoamingEquipped with built‑in vacuum unit, MIX650 requires no regular pump‑oil replacement for maintenance‑free operation with zero environmental pollution, ideal for clean‑room application. Vacuum level adjustable from ‑98 kPa to 0 kPa for flexible parameter setting according to material viscosity and bubble characteristics. The built‑in design eliminates external vacuum pump piping and extra space occupation with high integration. Vacuum defoaming starts right after power‑on to shorten production‑line changeover time. | 500 mL Medium‑capacity with Wide‑range Speed Regulation500 mL dual‑cup configuration fits pilot R&D and continuous production sampling. Dual‑cup simultaneous operation improves batch efficiency. 0‑2000 rpm wide‑range speed covers low‑/medium‑/high‑viscosity materials. Low speed for gentle mixing & defoaming of high‑viscosity adhesives; high speed for fast dispersion of low‑viscosity coating liquids. Synchronized revolution‑rotation dual power completes mixing and defoaming within approx. 1 minute. | Flexible Multi‑segment Program Process EditingMicrocomputer control system stores 100 sets of programs. Each program supports multi‑segment independent time & speed setting for multi‑stage process configuration. User permission management & fault indication support multi‑operator shared usage. Program‑driven operation reduces manual adjustment errors and guarantees consistent batch‑to‑batch performance. |
✨ MIX650 integrates three core capabilities: built‑in maintenance‑free vacuum, 500 mL medium‑capacity dual‑cup with wide‑range speed regulation, and flexible multi‑segment program editing. It is suitable for pilot‑scale R&D and production sampling of materials for electronic encapsulation, medical device bonding, aerospace composite materials and more.
Working Principle
Synchronized revolution‑rotation dual‑power operation realizes one‑step mixing and defoaming.
Step 1: Centrifugal Force Generated by Revolution High‑speed rotating revolution turntable generates centrifugal force for materials inside containers to drive full‑range convection and achieve macro‑mixing. Meanwhile, centrifugal force pushes low‑density bubbles toward the rotating axis for aggregation and escape. Stable revolution speed ensures consistent mixing performance for each batch. Step 2: Shear Force Provided by Rotation Containers spin around their own axis to generate directional shear force for breaking agglomerated particles and realizing micro‑dispersion. Precisely calculated fixed revolution‑rotation speed ratio ensures high‑efficiency full‑range mixing. Shear force thins bubble membranes and accelerates bubble rupture. No built‑in impeller contacts materials, lowering risk of metal‑chip contamination and preserving material chemical properties. Step 3: Deep Defoaming Under Vacuum Negative Pressure The built‑in vacuum unit draws gas to form negative‑pressure environment, reducing pressure difference inside and outside bubbles so deep‑seated micro‑bubbles expand and escape. Adjustable vacuum from ‑98 kPa to 0 kPa adapts to defoaming requirements of various‑viscosity materials. Built‑in vacuum unit runs maintenance‑free with no regular pump‑oil replacement and zero environmental pollution. Synchronized revolution‑rotation combined with vacuum negative pressure completes the full‑flow "Mixing → Dispersion → Vacuum Defoaming" inside sealed containers with built‑in maintenance‑free vacuum. |  |
Technical Specifications
Complete Technical Specifications Overview, Customizable on Demand
| Model | SIE‑MIX650 |
| Mixing Capacity | 0–500 mL (standard container) * Larger volume customizable |
| Container Type | Test tube / Can / Cup; adapters for syringe & cartridge available |
| Quantity of Containers | 1 or 2 cans (user‑selectable) |
| Max Speed | 0 – 2000 RPM (stepless adjustable) |
| Revolution / Rotation Ratio | Fixed planetary ratio |
| Vacuum Degree | Standard: –98 kPa / Optional: –100 kPa |
| Control System | Touch screen, stores up to 100 recipe sets |
| Power Supply | 220V, 50/60Hz (110V US‑JP standard customizable) |
| Overall Dimension(W×D×H) | 580 × 560 × 760 mm |
| Net Weight | 145 kg |
| Certifications | CE, FC, ISO9001, RoHS Compliance |
Our Partners
Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide
FAQ - Frequently Asked Questions
Answers to common questions about product performance and everyday process selection
-
脱泡机的作用是什么？
脱泡机是一种用于去除液体中的气泡的设备。它的作用在于帮助生产过程中的液体混合、反应、涂布、印刷、灌注等工艺环节，避免气泡的产生和对最终产品的影响。在许多工业和实验室环境中，去除气泡是非常必要的，因为气泡可能会对产品质量产生负面影响，如影响表面张力和稳定性等问题。脱泡机通常采用各种不同的技术，如振动、超声波、离心等，以实现有效的气泡去除。它的应用领域广泛，包括但不限于半导体、太阳能、光学、生物技术、材料科学等。
-
售后服务怎么样？
公司拥有专业的售后服务人员，24小时专人服务，一对一提供技术支持，解决您的后顾之忧。
-
为什么要选择施诺斯？
选择施诺斯的原因有很多，以下是一些主要的原因：
1. 专业性：我们的团队由一群专业的人士组成，他们在各自的领域拥有丰富的经验和知识。我们不仅了解行业趋势和最佳实践，而且还能提供切实可行的解决方案。
2. 服务质量：我们注重客户的需求和满意度，始终致力于提供高质量的服务。我们不仅快速响应客户需求，而且还能根据客户的要求进行定制化服务。
3. 可靠性：我们以诚信和专业精神为宗旨，始终遵守承诺和协议。我们的工作方法和交付成果均符合行业标准和最佳实践，使得我们的客户能够信任我们。
4. 创新性：我们不断探索新的方法和工具，以提供更好的服务并满足客户的需求。我们鼓励创新和实验，并愿意接受挑战和改变。
5. 成本效益：我们提供高性价比的服务，不仅能够帮助客户节省成本，而且还能提高效率和生产力。我们始终以客户的利益为出发点，为客户提供最优的解决方案。
6. 团队合作：我们相信团队的力量和合作的价值，我们的团队成员之间互相支持、协作和尊重。我们与客户、合作伙伴和其他利益相关者建立紧密的合作关系，以实现共同的目标。
以上只是选择我们的部分原因，我们相信还有很多其他的优点和价值可以为客户提供。如果您正在寻找一家专业、可靠、高质量的服务提供商，我们非常期待与您的合作。
-
搅拌脱泡机的工作原理？
施诺斯搅拌脱泡机通过公转的离心力进行脱泡，通过公转与自转形成的剪切力进行搅拌，
再辅助以真空泵抽取气体以达到真空状态，去除纳米级微小气泡。 不接触物料，无二次污染，无二次浪费。
-
施诺斯能提供工程咨询技术服务吗？
施诺斯能为广大客户提供全面的工程和现代化的咨询服务。施诺斯近二十年的搅拌经验，可以为你提供高效的咨询服务。
想要让搅拌机性能更上一层楼，提升系统的整体效能？我们有全面的咨询、工程以及现代化改造服务，为您量身打造解决方案。 在如今竞争激烈的全球化浪潮中，唯有不断创新、持续优化，才能始终跑在对手前面。您的生产工艺和产品日新月异，我们就为您提供最适配的混合技术。不管是新的产品参数，还是既有的工艺条件，我们都能对现有系统和搅拌设备进行全方位的检查与评估，挖掘其中潜藏的流程优化空间和机械性能提升潜力，并且帮您把这些改进切实落地。 要是您的搅拌设备已经跟不上时代步伐，能耗居高不下，或是维护成本让您头疼不已，那就别犹豫，我们的咨询、工程设计和现代化改造服务，就是为您排忧解难的良方。欢迎随时联系我们，携手开启高效生产新征程！
Technical Specification List
Full‑line standardized specifications for accurate process evaluation and equipment selection
| Model | SIE‑MIX60 | SIE‑MIX650 | SIE‑MIX90 |
| Mixing Capacity | 0–300 mL (standard container) * Customizable | 0–500 mL (standard container) * Customizable | 0–1000 mL (standard container) * Customizable |
| Container Type | Test tube / Can / Cup; adapters for syringe & cartridge available | Test tube / Can / Cup; adapters for syringe & cartridge available | Test tube / Can / Cup; adapters for syringe & cartridge available |
| Quantity of Containers | 1 or 2 cans (user‑selectable) | 1 or 2 cans (user‑selectable) | 1 or 2 cans (user‑selectable) |
| Max Speed | 0 – 3000 RPM (stepless adjustable) | 0 – 2000 RPM (stepless adjustable) | 0 – 2000 RPM (stepless adjustable) |
| Revolution / Rotation Ratio | Fixed planetary ratio | Fixed planetary ratio | Fixed planetary ratio |
| Vacuum Degree | Standard: –98 kPa / Optional: –100 kPa | Standard: –98 kPa / Optional: –100 kPa | Standard: –98 kPa / Optional: –100 kPa |
| Control System | Touch screen, stores up to 100 recipe sets | Touch screen, stores up to 100 recipe sets | Touch screen, stores up to 100 recipe sets |
| Power Supply | 220V, 50/60Hz (110V US‑JP standard customizable) | 220V, 50/60Hz (110V US‑JP standard customizable) | 220V, 50/60Hz (110V US‑JP standard customizable) |
| Overall Dimension(W×D×H) | 510 × 430 × 500 mm | 580 × 560 × 760 mm | 610 × 560 × 780 mm |
| Net Weight | 95 kg | 145kg | 153 kg |
| Certifications | CE, FC | CE, FC | CE, FC |
*** The above are typical models only. Customized solutions are available upon customer requirements.
Multi‑Industry Solutions
Provide customized solutions to meet comprehensive demands from cutting‑edge R&D to large‑scale mass production
Electronics IndustryEpoxy Potting Adhesive, Conductive Silver Adhesive, Electronic Slurry, UV Adhesive, Thermal‑conductive Gel |
Aerospace & Defense IndustryComposite Matrix Resin, Structural Adhesive, Radar‑absorbing Coating, Functional Coating Liquid |
Medical Device IndustryMedical Adhesive, Sensor Potting Adhesive, Catheter Coating Liquid, Diagnostic Reagent Carrier |
Chemical IndustryResin Casting Compound, Resin Solution, Catalyst Slurry, Reactive Adhesive |
Adhesive & Sealant IndustryStructural Adhesive, Sealant, Conductive Adhesive, High‑temperature Adhesive |
3D Printing IndustryPhotosensitive Resin, Functional Ink, Ceramic Slurry, Composite Prepreg |
Comprehensive Equipment Operation Demo Videos
Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.
Measured Defoaming‑Process Performance
Thoroughly eliminate material bubbles, voids and stratification
UV Adhesive |
Epoxy Resin |
Polymer Materials |
Pharmaceutical Gel |
Silver Paste Material |
Battery Slurry |
Measured Data Comparison
Quantifiable Effects Validated by Test Data
| Material Type | Status Before Treatment | After MIX650 Treatment |
| Epoxy Potting Adhesive | Dense internal bubbles, ~5% encapsulation void rate, unstable insulation performance | Bubbles removed, encapsulation void rate <0.5%, stable insulation property |
| Lithium‑ion Battery Cathode Slurry | Heavy internal bubbles, ~6% coating pinhole rate, large thickness deviation | Bubbles removed, coating pinhole rate <1%, uniform thickness |
| Thermal‑conductive Grease | Numerous bubbles, agglomerated thermal‑conductive powder, thermal conductivity deviation ±15% | Uniform powder dispersion, bubbles removed, thermal conductivity deviation ±3% |
* Internal lab test data. Actual improvement varies with material formula. Contact sales for real customer cases.
