Laboratory Planetary Ball Mill SIE-BM80


Heatable & Coolable Rollers for Temperature-controlled Grinding · 80mm rollers for small-batch multi-grade production · Standard circulating cooling water

Roller heating & cooling control + 3-18μm fineness + circulating cooling water for stable quality

SIENOX SIE-SG80 precision three-roll mill. 80mm×200mm rollers support heating and cooling, grinding fineness reaches 3-18μm after 3 passes. Equipped with standard circulating cooling water system. Designed for small-batch & multi-variety production. Temperature control preserves quality of heat-sensitive materials, suitable for coatings, pharmaceuticals, food and more industries.

✓ CE certification  ✓ FC certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Custom voltage available (110V/220V)

Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Precision Grinding Is Required

Coarse particles & poor dispersion impair final product quality.

Printing Ink Industry

Coarse pigment particles in lab ink formulas cause uneven hue and poor color development, undermining formula evaluation. Three-roll mill disperses pigments to micron level for uniform hue and reliable repeatable test data.

Cosmetics Industry

Gritty texture in lipstick and foundation hurts smoothness and gloss. Three-roll milling delivers creamy paste, boosts product quality, and verifies end performance in small trial batches.

Electronic Slurry Industry

Agglomerated silver powder in conductive paste causes broken screen printing lines and unstable resistance. Three-roll mill evenly disperses silver powder for consistent printing and accurate lab formula tests.

✨ Traditional grinding challenges: High-speed dispersers only disperse without real milling, failing fineness targets. Sand mills introduce impurities from worn media and contaminate valuable samples. Manual grinding is slow, inconsistent, and operator-dependent.

Why Choose SIE-SG80

Solve core pain points of small-batch grinding

Micron-level Precision Grinding

Precisely ground rollers with high parallelism and uniform gap across full length. Matte roller surface ensures good slurry adhesion. Roll ends are cold-pressed with heavy interference fit for solid connection. Repeated grinding achieves fine particle size to meet R&D fineness requirements.

Precise Speed Control by DC Governor

DC motor with adjustable speed, freely set according to material viscosity & target fineness. High speed for low-viscosity materials to boost efficiency; low speed for high-viscosity materials for uniform dispersion. Triangular belt and gear train drive rollers reliably for controllable grinding.

Compact Benchtop Design

Ideal for lab benchtop use. Small footprint, easy to move, fits limited lab space, no foundation required, ready after power-on. Removable feeding copper blade for easy cleaning and quick material changeover.


✨ SG80 is ideal for small batches with temp grinding, frequent changeover or heat-sensitive materials.

Working Principle

Based on planetary motion principle

What other devices adopt planetary motion principle besides SG80?

Planetary ball mill operates on planetary motion principle. Grinding jars are mounted on the main sun disk. While the disk revolves around the central axis, grinding jars rotate rapidly on their own axes in the opposite direction.



Under this compound motion, grinding balls inside jars are subjected to alternating forces:

Impact Force: Grinding balls are flung at high speed to crush coarse particles.

Friction and Shear Force: High-frequency friction and shear between balls and jar walls realize fine grinding and dispersion.


When centrifugal acceleration from revolution exceeds the critical value, balls are pressed against jar walls and rotate together with jars without effective grinding. Proper speed setting and transmission ratio are key to grinding efficiency. SIENOX models adopt optimized transmission ratios to achieve high centrifugal acceleration within valid speed ranges for efficient grinding.


Typical Grinding Parameters:

Sample Loading: ≤ 2/3 of jar volume (including grinding media and samples)

Media Filling Ratio: 1/3 to 1/2 of jar volume

Typical Grinding Time: 5–60 min (depends on material hardness and target fineness)

Final Fineness: down to <0.1μm (varies with material, parameters and media selection)

Three Roll Mill Working Principle.png

Technical Specifications

Complete Technical Specifications Overview, Customizable on Demand

ModelSIE-BM80-1S (Single Jar)SIE-BM80-2S (Dual Jars)
Max. Feed Size≤5mm≤5mm
Sun Disk Speed100–900 rpm continuously adjustable100–800 rpm continuously adjustable
Effective Sun Disk Diameter290mm290mm
Final Fineness<0.1μm<0.1μm
Grinding Media Size0.1–15mm0.1–15mm
Grinding ModeDry / Wet GrindingDry / Wet Grinding
Safety ProtectionAuto-stop on lid openingAuto-stop on lid opening
Power SupplyAC 220V / 50Hz, 0.55KWAC 220V / 50Hz, 0.75KW
Overall Dimension(W×D×H)520×360×440mm520×360×440mm
Net WeightApprox. 48kgApprox. 56kg
CertificationsCE, FC, ISO9001, RoHS ComplianceCE, FC, ISO9001, RoHS Compliance

Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • What is the working principle of a centrifugal defoaming machine?

    Principle of centrifugal defoaming machine: The bubbles are released by the downward principle of gravity.

  • How is the after-sales service?

    The company has professional after-sales service personnel, 24-hour dedicated service, and one-on-one technical support to solve your worries.

  • Why choose SIENOX?

    There are many reasons for choosing SIENOX, and the following are some of the main reasons:

    1. Professionalism: Our team consists of a group of professional individuals with rich experience and knowledge in their respective fields. We not only understand industry trends and best practices, but also provide practical and feasible solutions.

    2. Service quality: We focus on customer needs and satisfaction, and are always committed to providing high-quality services. We not only respond quickly to customer needs, but also provide customized services according to their requirements.

    3. Reliability: We adhere to the principles of integrity and professionalism, always adhering to commitments and agreements. Our work methods and deliverables comply with industry standards and best practices, enabling our clients to trust us.

    4. Innovation: We continuously explore new methods and tools to provide better services and meet customer needs. We encourage innovation and experimentation, and are willing to accept challenges and change.

    5. Cost effectiveness: We provide cost-effective services that not only help customers save costs, but also improve efficiency and productivity. We always prioritize the interests of our customers and provide them with the best solutions.

    6. Teamwork: We believe in the power and value of teamwork, and our team members support, collaborate, and respect each other. We establish close cooperative relationships with customers, partners, and other stakeholders to achieve common goals.

    The above are just some of the reasons for choosing us. We believe there are many other advantages and values that can be provided to customers. If you are looking for a professional, reliable, and high-quality service provider, we look forward to working with you.


  • How does the stirring and defoaming machine work?

    The SIENOX stirring and defoaming machine performs defoaming through centrifugal force at revolution and stirring through shear force formed by revolution and rotation,

    Assisted by a vacuum pump to extract gas and achieve a vacuum state, removing nanoscale tiny bubbles. No contact with materials, no secondary pollution, and no secondary waste.

  • What is the function of a defoaming machine?

    A defoaming machine is a device used to remove bubbles from liquids. Its function is to assist in the liquid mixing, reaction, coating, printing, infusion and other process steps in the production process, avoiding the generation of bubbles and their impact on the final product. In many industrial and laboratory environments, removing bubbles is essential as they may have a negative impact on product quality, such as affecting surface tension and stability. Defoaming machines typically use various techniques such as vibration, ultrasound, centrifugation, etc. to achieve effective bubble removal. It has a wide range of applications, including but not limited to semiconductors, solar energy, optics, biotechnology, materials science, etc.

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

ModelSIE-BM80SIE-BM500SIE-BM1000
Max. Jar Volume80mL500mL1000mL
Max. Feed Size≤5mm≤10mm≤10mm
Sun Disk Speed100–900 rpm continuously adjustable100–700 rpm continuously adjustable100–320 rpm continuously adjustable
Effective Sun Disk Diameter290mm290mm430mm
Final Fineness<0.1μm<0.1μm<0.1μm
Grinding Media Size0.1–15mm0.5–20mm0.5–25mm
Grinding ModeDry / Wet GrindingDry / Wet GrindingDry / Wet Grinding
Safety ProtectionAuto-stop on lid openingAuto-stop on lid openingAuto-stop on lid opening
Power SupplyAC 220V / 50Hz, 0.55-0.75KWAC 220V / 50Hz, 0.75–1.1KWAC 220V / 50Hz, 1.5KW
Overall Dimension(W×D×H)520×360×440mm520×360×440mm520×360×440mm
Net WeightApprox. 48-56kgApprox. 85-162kgApprox. 155kg
CertificationsCE, FC, ISO9001, RoHS ComplianceCE, FC, ISO9001, RoHS ComplianceCE, FC, ISO9001, RoHS Compliance

***The above are typical models. SIENOX provides customized solutions upon request. For selection consultation: 189-2512-9293

Multi‑Industry Solutions

Covers mixing & defoaming applications for typical materials across six major industries.


Adhesive R&D

Epoxy structural adhesive, sealant, hot melt adhesive, pressure-sensitive adhesive, modified adhesive

Precision Optics.jpg

Precision Electronic Assembly

Underfill, conductive adhesive, die attach adhesive, dispensing adhesive, chip bonding adhesive

Electronic Materials.jpg

Biosensors

Encapsulation adhesive, reagent immobilization material, microfluidic bonding glue, biocompatible adhesive, sensor sealant

Thermal Silicone.jpg

Microelectronic Packaging

Packaging epoxy, molding compound, lead bonding adhesive, substrate bonding adhesive, passivation layer material

Medical Devices02.jpg

Functional Coatings

Hydrophobic coating, conductive coating, insulating coating, anti-corrosion coating, wear-resistant coating

Photosensitive Materials.jpg

Electronic Slurries

Silver paste, copper paste, carbon paste, resistance paste, dielectric paste

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Measured Defoaming‑Process Performance

Measured Processing Results for Six Typical Materials

Lubricant Mixing & Defoaming.jpg

Paste Materials

Photoresist Mixing & Defoaming.jpg

Adhesive with Powder

Polymer Materials.jpg

Polymer Materials

Gel Defoaming 02.jpg

Pharmaceutical Gels

Silver Paste Mixing & Defoaming.jpg

Silver Paste Materials

Battery Slurry & Adhesive Mixing Defoaming.jpg

Battery Slurries



Optional Accessories

Accessory NameDescription
Grinding Jars of Various MaterialsStainless steel, agate, zirconia, tungsten carbide, alumina ceramic, silicon nitride, nylon, PTFE. Selected according to machine model.
Grinding Media (Balls)Matching balls in corresponding materials, size Φ0.1–30mm. Single size or mixed grading packages available.
Vacuum Grinding JarsStainless steel / agate / zirconia, fitted with vacuum sealing valve. Support vacuum pumping and inert gas shielding milling.

* Internal lab test data. Actual improvement varies with material formula. Contact sales for real customer cases.
