Centrifugal Defoaming Machine SIE‑C006


Compact Silent Centrifugal Defoamer for Glove‑box Use · Non‑contact Gravity Defoaming Preserves Material Properties

Glove‑box compatible operation + 6‑tube simultaneous defoaming without queuing + silent running for undisturbed workflow

SIENOX SIE‑CV200 is a benchtop planetary mixing‑defoaming machine developed for laboratory research and small‑sample tests. It requires no extra floor space and can be placed directly on lab benches. The 200 mL small‑volume capacity matches regular lab consumption and reduces material waste.

SIENOX SIE‑C006 centrifugal defoaming machine fits inside standard glove boxes and processes six small samples simultaneously. Simple intuitive mechanical panel control and patented silent design suit lab and office environments. Non‑contact gravity‑driven defoaming keeps chemical properties unchanged and lowers material contamination risks. It works for phosphor powder, epoxy resin, ceramic slurry, photosensitive resin and other common lab materials.

 ✓ FCC Certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Customizable voltage (110V/220V)


Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Must Microbubbles in Materials Be Eliminated?

Residual micro‑bubbles in materials directly degrade end‑product quality.

Laboratory R&D

Repeated small‑sample tests in R&D suffer from non‑reproducible data caused by bubbles. Large deviations between duplicate experiments waste precious samples and delay progress. Centrifugal defoaming runs non‑contact inside sealed syringes to keep samples pure for reliable repeatable test results.

Medical Consumables

Bubbles in dental resins and diagnostic reagents reduce product pass rate. Cured voids degrade mechanical properties and cause scrap. High‑cleanliness requirements are met by stirrer‑free centrifugal defoaming which prevents secondary contamination for clean‑room operation.

Touch‑screen Industry

Residual bubbles in silver paste trigger screen‑printing disconnections, pinholes and uneven sheet resistance, lowering yield. Non‑contact centrifugal bubble separation guarantees consistent printing performance and improves production yield.

✨ Limitations of Conventional Methods: Manual stirring or standard agitator paddles draw in air actively and generate more bubbles with stirring. Static defoaming takes long time with limited performance. Laboratories require professional non‑contact planetary mixing‑defoaming equipment, which separates bubbles while mixing via centrifugal force to ensure consistent and reproducible experimental data for every test.

Why Choose SIE‑C006

Three Core Advantages Tailored for Laboratory Research Scenarios

Glove‑box Compatible Operation

Compact footprint fits inside standard glove boxes for direct defoaming under inert‑gas atmosphere. Air‑sensitive materials such as organolithium reagents, metal‑organic compounds and oxidizable polymers can be defoamed without taking them out of the box to prevent air‑induced deterioration.

Multi‑station Simultaneous Defoaming

Processes six samples at one time with six syringes without sequential waiting. Multiple syringe sizes (3/5/10/30cc) are available for different experimental volumes. Tubular containers are ready‑to‑use; one setting completes defoaming for multiple comparative test groups simultaneously.

Patented Silent Design

Unique patented design delivers strong centrifugal force for thorough and efficient defoaming. Low‑noise operation makes it suitable for lab benchtops or office desks without disturbing surrounding work, ideal for noise‑sensitive research and office environments.

✨ If you have limited lab‑bench space, work with air‑sensitive materials, or expect quiet small‑sample defoaming near office areas, the C006 is your ideal choice.

Working Principle

Bubbles escape under downward gravity to efficiently eliminate micro‑bubbles inside materials and improve product quality.

Step 1: High-speed centrifugal separation. Set speed and time via control panel. Centrifugal force generated by high rotation separates bubbles from materials.

Step 2: Gravity-driven escape. Gravity pulls materials downward while bubbles rise to the surface and escape.

Step 3: Non-contact purity preservation. Materials rotate inside sealed syringes without mixing blades contact, leaving chemical properties unchanged.


Three simple steps: Centrifugal Separation → Gravity Escape → Non-contact Purity Preservation. Defoaming finished in one cycle.

Centrifugal Defoaming Machine Working Principle.jpg

Technical Specifications

Complete Technical Specifications Overview, Customizable on Demand

ModelSIE‑C006
Mixing Capacity3/5/10/30cc* Larger volume customizable
Vessel TypeTest tube (jar optional)
Syringe Quantity6 pcs
Max Rotation Speed100 – 4000 RPM (stepless adjustable)
Standard Accessories6 × tubular syringes
Safety Lock DeviceYes
Control SystemMechanical panel, stores 100 sets of formula parameters
Power Supply220V, 50/60Hz (110V US/JP standard customizable)
Overall Dimension(W×D×H)560×640×370mm
Net WeightApprox.32 kg
CertificationsFCC, ISO9001, RoHS Compliance



Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • What is the working principle of a centrifugal defoaming machine?

    Principle of centrifugal defoaming machine: The bubbles are released by the downward principle of gravity.

  • How is the after-sales service?

    The company has professional after-sales service personnel, 24-hour dedicated service, and one-on-one technical support to solve your worries.

  • Why choose SIENOX?

    There are many reasons for choosing SIENOX, and the following are some of the main reasons:

    1. Professionalism: Our team consists of a group of professional individuals with rich experience and knowledge in their respective fields. We not only understand industry trends and best practices, but also provide practical and feasible solutions.

    2. Service quality: We focus on customer needs and satisfaction, and are always committed to providing high-quality services. We not only respond quickly to customer needs, but also provide customized services according to their requirements.

    3. Reliability: We adhere to the principles of integrity and professionalism, always adhering to commitments and agreements. Our work methods and deliverables comply with industry standards and best practices, enabling our clients to trust us.

    4. Innovation: We continuously explore new methods and tools to provide better services and meet customer needs. We encourage innovation and experimentation, and are willing to accept challenges and change.

    5. Cost effectiveness: We provide cost-effective services that not only help customers save costs, but also improve efficiency and productivity. We always prioritize the interests of our customers and provide them with the best solutions.

    6. Teamwork: We believe in the power and value of teamwork, and our team members support, collaborate, and respect each other. We establish close cooperative relationships with customers, partners, and other stakeholders to achieve common goals.

    The above are just some of the reasons for choosing us. We believe there are many other advantages and values that can be provided to customers. If you are looking for a professional, reliable, and high-quality service provider, we look forward to working with you.


  • How does the stirring and defoaming machine work?

    The SIENOX stirring and defoaming machine performs defoaming through centrifugal force at revolution and stirring through shear force formed by revolution and rotation,

    Assisted by a vacuum pump to extract gas and achieve a vacuum state, removing nanoscale tiny bubbles. No contact with materials, no secondary pollution, and no secondary waste.

  • What is the function of a defoaming machine?

    A defoaming machine is a device used to remove bubbles from liquids. Its function is to assist in the liquid mixing, reaction, coating, printing, infusion and other process steps in the production process, avoiding the generation of bubbles and their impact on the final product. In many industrial and laboratory environments, removing bubbles is essential as they may have a negative impact on product quality, such as affecting surface tension and stability. Defoaming machines typically use various techniques such as vibration, ultrasound, centrifugation, etc. to achieve effective bubble removal. It has a wide range of applications, including but not limited to semiconductors, solar energy, optics, biotechnology, materials science, etc.

Multi‑model Comparison Table

Full‑line standardized specifications for accurate process evaluation and equipment selection

ModelSIE‑C006SIE‑C008SIE‑C012
Mixing Capacity3/5/10/30cc* Customizable3/5/10/30cc* Customizable3/5/10/30cc* Customizable
Vessel TypeTest tube (jar optional)Test tube (jar optional)Test tube (jar optional)
Syringe Quantity6 pcs8 pcs12 pcs
Max Rotation Speed100 – 4000 RPM (stepless adjustable)100 – 4500 RPM (stepless adjustable)100 – 4500 RPM (stepless adjustable)
Standard Accessories6 × tubular syringes8 × tubular syringes12 × tubular syringes
Safety Lock DeviceYesYesYes
Control SystemMechanical panel, stores 100 sets of formula parametersMechanical panel, stores 100 sets of formula parametersMechanical panel, stores 100 sets of formula parameters
Power Supply220V, 50/60Hz (110V US/JP standard customizable)220V, 50/60Hz (110V US/JP standard customizable)220V, 50/60Hz (110V US/JP standard customizable)
Overall Dimension(W×D×H)560×640×370mm630×740×380mm660×740×380mm
Net Weight32 kg45 kg65 kg
CertificationsFCCFCCFCC

***Above are typical models only. SIENOX provides customized solutions upon client requirements. Contact sales for model selection: 189‑2512‑9293

Multi‑Industry Solutions

Covers mixing‑defoaming applications for typical R&D and experimental materials across six industries.


University & Research Institutes

New material synthesis, nanomaterial dispersion, polymer research, alumina slurry, functional materials


Biopharmaceuticals

Diagnostic reagents, drug sustained‑release formulations, pharmaceutical gels, vaccine adjuvants, biological adhesives


Fine Chemicals

Coating formulation, pigment dispersion, adhesive R&D, surface treatment agents, catalyst slurries


LED Packaging

Phosphor dispersion, packaging silicone, optical adhesive, color‑matching slurry, reflective adhesive


Aerospace

Conductive adhesive, structural adhesive, composite resin, coating materials, high‑temperature adhesive


Testing Laboratories

Standard sample preparation, reference sample production, incoming material inspection, quality analysis samples

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Actual‑test Performance Demonstration

Lab Sample Actual Test Results

UV Adhesive Defoaming 02.jpg

UV Adhesive

UV Adhesive Defoaming.jpg

UV Adhesive

Gel Defoaming 02.jpg

Pharmaceutical Gel

Lubricant Mixing & Defoaming.jpg

Lubricant

Polymer Material.jpg

Polymer Material

High‑viscosity Glue Before‑after Defoaming 01.jpg

High‑viscosity Glue

Actual‑test Effect Comparison

Material Defoaming Effect Comparison (Before & After)

Material TypeState Before TreatmentAfter Treatment by C006
Ceramic SlurryTurbid and whitish slurry with thick foam layer on surface after mixing, numerous forming defectsTransparent and uniform slurry, smooth foam-free surface, dense forming
Dental ResinVisible bubbles inside resin, voids after curing, fluctuating mechanical propertiesClear transparent resin, dense and void-free after curing with stable performance
Touch Silver PasteBubbles inside silver paste, broken lines and pinholes during screen printing, uneven sheet resistanceSmooth and uniform silver paste, continuous screen printing without breakage, consistent sheet resistance

* Internal lab test data. Actual improvement varies with material formulation. Contact sales for real customer cases.

Customer Delivery & Application Cases

Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.


BOX Single‑Component Epoxy Adhesive Defoaming Solution: SIENOX Planetary Defoaming Machine


SIENOX Planetary Stirring‑Defoaming Machine Enables High‑reliability Structural‑Adhesive Bonding Solutions


Silicone Rubber Material Stirring & Defoaming Solution
