Centrifugal Defoaming Machine SIE‑C008


High‑Centrifugal‑Force Driven Deep Defoaming · 8‑Tube Parallel Processing with Reproducible Recipes

4500rpm high‑centrifugal‑force deep defoaming + 8‑station parallel operation + one‑click recall for 100 recipe sets

SIENOX SIE‑CV200 is a desktop planetary stirring‑defoaming machine developed for laboratory research and small‑sample tests. It requires no extra floor space and can be placed directly on lab benches. The 200mL small‑sample capacity matches regular research‑lab consumption and reduces material waste.

SIENOX SIE‑C008 centrifugal defoaming machine processes 8 syringes simultaneously. Wide speed range 100‑4500rpm adapts to materials of various viscosities. 100‑set recipe storage saves and reproduces process parameters without re‑adjustment during material change. Mechanical panel operation with low‑noise design, ideal for shared lab environments.

✓ FCC Certification ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Customizable Voltage (110V/220V)

Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Must Microbubbles in Materials Be Eliminated?

Residual micro‑bubbles in materials directly affect end‑product quality.

Laboratory R&D Field

Repeated small‑sample tests in R&D suffer from non‑reproducible test data caused by bubbles. Significant result deviations occur between two runs of the same material, wasting valuable samples and delaying R&D progress. Centrifugal defoaming performs non‑contact processing inside sealed syringes to ensure sample purity and reliable, reproducible data.

Medical Consumable Industry

Bubbles in dental resins and diagnostic reagents directly reduce product pass rates. Voids after curing degrade mechanical properties and may cause total product rejection. Meeting strict medical cleanliness requirements, centrifugal defoaming avoids secondary contamination without stirrer contact, suitable for defoaming in clean environments.

Touch‑screen Industry

Residual bubbles in touch‑screen silver paste trigger screen‑printing open circuits and uneven sheet resistance, lowering yield rates. Non‑contact bubble separation via centrifugal defoaming guarantees consistent screen‑printing performance for conductive slurries and improves production yield.

✨ Dilemmas of conventional methods: Manual stirring or ordinary stirrer paddles draw in air actively, generating more bubbles with stirring. Static defoaming takes long time with limited effect. Laboratories need professional non‑contact planetary stirring‑defoaming equipment, which separates bubbles while mixing via centrifugal force to ensure consistency and reproducibility of experimental data for every run.

Why Choose SIE‑C008

Three Core Advantages Built for Laboratory Research Scenarios

High‑centrifugal‑force Defoaming

Max 4500 RPM delivers powerful centrifugal force for deep defoaming of high‑viscosity materials, and fast processing for low‑viscosity materials. Starting at 100 RPM for splash‑prone substances, the broad speed range flexibly fits diverse material properties. One unit meets multi‑material defoaming demands for lab teams.

Multi‑station Simultaneous Defoaming

8 syringes process 8 samples in one run; multiple lab samples finish in parallel without queuing. Five syringe sizes 3/5/10/30/55 cc available, covering small‑scale tests to medium‑volume pre‑treatment. Tubular containers are ready‑to‑use; jar‑type containers are optional.

Storage for 100 Recipe Sets

Process parameters can be saved and reproduced. One‑click recall of different material recipes eliminates re‑setting speed and time upon material change. It prevents repeated trial‑and‑error from forgotten parameters, cuts material waste, delivers consistent batch results and enables traceable, comparable experimental data.

✨ If your team processes multi‑variant materials, pursues process reproducibility, or handles hard‑to‑defoam high‑viscosity materials, C008’s 8‑tube parallel processing and recipe storage effectively boost efficiency.

Working Principle

Bubbles escape downward by gravity principle to efficiently eliminate micro‑bubbles and improve product quality.

Step 1: High-speed centrifugal separation. Set speed and time via control panel. Centrifugal force generated by high rotation separates bubbles from materials.

Step 2: Gravity-driven escape. Gravity pulls materials downward while bubbles rise to the surface and escape.

Step 3: Non-contact purity preservation. Materials rotate inside sealed syringes without mixing blades contact, leaving chemical properties unchanged.


Three simple steps: Centrifugal Separation → Gravity Escape → Non-contact Purity Preservation. Defoaming finished in one cycle.

Centrifugal Defoaming Machine Working Principle.jpg

Technical Specifications

Complete Technical Specifications Overview, Customizable on Demand

ModelSIE‑C008
Mixing Capacity3/5/10/30/55cc* Larger volume customizable
Vessel TypeTest tube (jar optional)
Syringe Quantity8 pcs
Max Rotation Speed100 – 4500 RPM (stepless adjustable)
Standard Accessories8 × tubular syringes
Safety Lock DeviceYes
Control SystemMechanical panel, stores 100 sets of formula parameters
Power Supply220V, 50/60Hz (110V US/JP standard customizable)
Overall Dimension(W×D×H)630×740×380mm
Net WeightApprox.45 kg
CertificationsFCC, ISO9001, RoHS Compliance



Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • What is the working principle of a centrifugal defoaming machine?

    Principle of centrifugal defoaming machine: The bubbles are released by the downward principle of gravity.

  • How is the after-sales service?

    The company has professional after-sales service personnel, 24-hour dedicated service, and one-on-one technical support to solve your worries.

  • Why choose SIENOX?

    There are many reasons for choosing SIENOX, and the following are some of the main reasons:

    1. Professionalism: Our team consists of a group of professional individuals with rich experience and knowledge in their respective fields. We not only understand industry trends and best practices, but also provide practical and feasible solutions.

    2. Service quality: We focus on customer needs and satisfaction, and are always committed to providing high-quality services. We not only respond quickly to customer needs, but also provide customized services according to their requirements.

    3. Reliability: We adhere to the principles of integrity and professionalism, always adhering to commitments and agreements. Our work methods and deliverables comply with industry standards and best practices, enabling our clients to trust us.

    4. Innovation: We continuously explore new methods and tools to provide better services and meet customer needs. We encourage innovation and experimentation, and are willing to accept challenges and change.

    5. Cost effectiveness: We provide cost-effective services that not only help customers save costs, but also improve efficiency and productivity. We always prioritize the interests of our customers and provide them with the best solutions.

    6. Teamwork: We believe in the power and value of teamwork, and our team members support, collaborate, and respect each other. We establish close cooperative relationships with customers, partners, and other stakeholders to achieve common goals.

    The above are just some of the reasons for choosing us. We believe there are many other advantages and values that can be provided to customers. If you are looking for a professional, reliable, and high-quality service provider, we look forward to working with you.


  • How does the stirring and defoaming machine work?

    The SIENOX stirring and defoaming machine performs defoaming through centrifugal force at revolution and stirring through shear force formed by revolution and rotation,

    Assisted by a vacuum pump to extract gas and achieve a vacuum state, removing nanoscale tiny bubbles. No contact with materials, no secondary pollution, and no secondary waste.

  • What is the function of a defoaming machine?

    A defoaming machine is a device used to remove bubbles from liquids. Its function is to assist in the liquid mixing, reaction, coating, printing, infusion and other process steps in the production process, avoiding the generation of bubbles and their impact on the final product. In many industrial and laboratory environments, removing bubbles is essential as they may have a negative impact on product quality, such as affecting surface tension and stability. Defoaming machines typically use various techniques such as vibration, ultrasound, centrifugation, etc. to achieve effective bubble removal. It has a wide range of applications, including but not limited to semiconductors, solar energy, optics, biotechnology, materials science, etc.

Multi‑model Comparison Table

Full‑line standardized specifications for accurate process evaluation and equipment selection

ModelSIE‑C006SIE‑C008SIE‑C012
Mixing Capacity3/5/10/30cc* Customizable3/5/10/30cc* Customizable3/5/10/30cc* Customizable
Vessel TypeTest tube (jar optional)Test tube (jar optional)Test tube (jar optional)
Syringe Quantity6 pcs8 pcs12 pcs
Max Rotation Speed100 – 4000 RPM (stepless adjustable)100 – 4500 RPM (stepless adjustable)100 – 4500 RPM (stepless adjustable)
Standard Accessories6 × tubular syringes8 × tubular syringes12 × tubular syringes
Safety Lock DeviceYesYesYes
Control SystemMechanical panel, stores 100 sets of formula parametersMechanical panel, stores 100 sets of formula parametersMechanical panel, stores 100 sets of formula parameters
Power Supply220V, 50/60Hz (110V US/JP standard customizable)220V, 50/60Hz (110V US/JP standard customizable)220V, 50/60Hz (110V US/JP standard customizable)
Overall Dimension(W×D×H)560×640×370mm630×740×380mm660×740×380mm
Net Weight32 kg45 kg65 kg
CertificationsFCCCFCCFCC

***Above are typical models only. SIENOX provides customized solutions upon client requirements. Contact sales for model selection: 189‑2512‑9293

Multi‑Industry Solutions

Covers stirring‑defoaming applications for typical R&D and experimental materials across six industries.

University‑level scientific research.jpg

University & Research Institutes

New material synthesis, nanomaterial dispersion, polymer research, alumina slurry, functional materials


Biopharmaceuticals

Diagnostic reagents, drug sustained‑release formulations, pharmaceutical gels, vaccine adjuvants, biological adhesives

Ink & coating.jpg

Fine Chemicals

Coating formulation, pigment dispersion, adhesive R&D, surface treatment agents, catalyst slurries

LED raw material 02.jpg

LED Packaging

Phosphor dispersion, packaging silicone, optical adhesive, color‑matching slurry, reflective adhesive


Aerospace

Conductive adhesive, structural adhesive, composite resin, coating materials, high‑temperature adhesive

Testing institution.jpg

Testing Laboratories

Standard sample preparation, reference sample production, incoming material inspection, quality analysis samples

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.


Actual‑test Performance Demonstration

Lab Sample Actual Test Results

UV Adhesive Defoaming 02.jpg

UV Adhesive

UV Adhesive Defoaming.jpg

UV Adhesive

Gel Defoaming 02.jpg

Pharmaceutical Gel

Lubricant Stirring‑Defoaming.jpg

Lubricant

Polymer Material.jpg

Polymer Material

High‑viscosity Adhesive Before‑after Defoaming 01.jpg

High‑viscosity Adhesive


Actual‑test Effect Comparison

Material Defoaming Effect Comparison (Before & After)

Material TypeState Before TreatmentAfter Treatment by C006
Ceramic SlurryTurbid and whitish slurry with thick foam layer on surface after mixing, numerous forming defectsTransparent and uniform slurry, smooth foam-free surface, dense forming
Dental ResinVisible bubbles inside resin, voids after curing, fluctuating mechanical propertiesClear transparent resin, dense and void-free after curing with stable performance
Touch Silver PasteBubbles inside silver paste, broken lines and pinholes during screen printing, uneven sheet resistanceSmooth and uniform silver paste, continuous screen printing without breakage, consistent sheet resistance

* Internal lab test data. Actual improvement varies with material formulation. Contact sales for real customer cases.
