Coating Degasser

TEL:18925129293

Epoxy Coating Defoaming Machine


Resolve pinholes and bubbles in epoxy coatings · Dense coating films, void-free anti-corrosion layers

Vacuum stirring & defoaming + Pigment and filler dispersion + Viscosity reduction and defoaming for high-build coatings

SIENOX epoxy coating defoaming solution addresses entrapped air bubbles and pigment agglomeration generated during stirring and spraying of epoxy zinc-rich primers, epoxy floor paints and anti-corrosion topcoats. Synchronous stirring and defoaming under vacuum produces dense coating films with favorable leveling performance and effectively reduces pinholes, craters and voids within anti-corrosion layers.

✓ CE certification  ✓ ISO9001 Quality System ✓ RoHS Compliance ✓ Custom voltage available (110V/220V)

Online Message Free Sample Testing Engineer Hotline: 189-2512-9293

Why Do We Need Epoxy Coating Defoaming Machine

Epoxy Anti-corrosion Coatings

Anti-corrosion paints such as epoxy zinc-rich and epoxy coal tar pitch for steel structures, pipelines and containers contain plenty of pigments and fillers. Air entrapment during stirring and spraying leads to pinholes and voids after curing, damaging the dense anti-corrosion layer.

Epoxy Floor Paint

Epoxy floor intermediate and top coats feature thick film thickness. Air trapped during stirring and troweling creates surface pinholes and pits after curing, impairing floor smoothness and wear resistance.

High-build Epoxy Coating

High-build, high-solid epoxy paints have high viscosity and abundant fillers. Bubbles hardly float up, frequently causing blisters and craters after spraying or roller coating with high recoating cost.

✨ Traditional Dilemma: Manual stirring of high-filler high-build coatings entraps air, resulting in pinholes and voids after curing. Sanding and recoating consume time and materials. Vacuum stirring & defoaming with filler dispersion is required.

Why Choose SIENOX Epoxy Coating Defoaming Solution

Simultaneous Defoaming & Dispersion

Stir and defoam under vacuum while breaking up pigment and filler agglomerates for dense coating films and uniform color.

Suitable for High-build Coatings

Heat high-viscosity high-build coatings to reduce viscosity before vacuum stirring, enabling bubbles to rise easily and improving leveling and film formation.

Full-stage Coverage

C/ZK series supports lab color matching, MIX series for scale-up mass production. Formulas can be replicated from sampling to production line.

✨ The MIX series is the ideal defoaming equipment for offset printing inks from color matching to bulk ink supply.

Equipment Supporting Description

Supporting Process Workflow

Weigh resin and powder → Vacuum stirring, mixing and degassing → Discharge for compacting / casting → Curing / sintering.

Stirring and Defoaming Working Principle 03.jpg

Specifications & Parameters

Selection Guide

Epoxy Coating TypeTypical StateRecommended Defoaming MethodRecommended Equipment
Color Matching / Sample PreparationSmall amount of coating materialCentrifugal / Vacuum DefoamingC Series / ZK Series
Epoxy Primer / TopcoatMedium-High ViscosityVacuum Stirring and DefoamingMIX60 / MIX80
Epoxy Floor Intermediate CoatHigh Viscosity High-buildVacuum Stirring and DefoamingMIX1000plus
High-filler Zinc-rich / High-build CoatingHigh Viscosity PasteVacuum stirring + Pressure Fine DefoamingMIX1000plus / RX Series

Our Partners

Trusted by leading industrial manufacturing clusters and advanced university laboratories worldwide

Partner Showcase

FAQ - Frequently Asked Questions

Answers to common questions about product performance and everyday process selection

  • What is the working principle of a centrifugal defoaming machine?

    Principle of centrifugal defoaming machine: The bubbles are released by the downward principle of gravity.

  • How is the after-sales service?

    The company has professional after-sales service personnel, 24-hour dedicated service, and one-on-one technical support to solve your worries.

  • Why choose SIENOX?

    There are many reasons for choosing SIENOX, and the following are some of the main reasons:

    1. Professionalism: Our team consists of a group of professional individuals with rich experience and knowledge in their respective fields. We not only understand industry trends and best practices, but also provide practical and feasible solutions.

    2. Service quality: We focus on customer needs and satisfaction, and are always committed to providing high-quality services. We not only respond quickly to customer needs, but also provide customized services according to their requirements.

    3. Reliability: We adhere to the principles of integrity and professionalism, always adhering to commitments and agreements. Our work methods and deliverables comply with industry standards and best practices, enabling our clients to trust us.

    4. Innovation: We continuously explore new methods and tools to provide better services and meet customer needs. We encourage innovation and experimentation, and are willing to accept challenges and change.

    5. Cost effectiveness: We provide cost-effective services that not only help customers save costs, but also improve efficiency and productivity. We always prioritize the interests of our customers and provide them with the best solutions.

    6. Teamwork: We believe in the power and value of teamwork, and our team members support, collaborate, and respect each other. We establish close cooperative relationships with customers, partners, and other stakeholders to achieve common goals.

    The above are just some of the reasons for choosing us. We believe there are many other advantages and values that can be provided to customers. If you are looking for a professional, reliable, and high-quality service provider, we look forward to working with you.


  • How does the stirring and defoaming machine work?

    The SIENOX stirring and defoaming machine performs defoaming through centrifugal force at revolution and stirring through shear force formed by revolution and rotation,

    Assisted by a vacuum pump to extract gas and achieve a vacuum state, removing nanoscale tiny bubbles. No contact with materials, no secondary pollution, and no secondary waste.

  • What is the function of a defoaming machine?

    A defoaming machine is a device used to remove bubbles from liquids. Its function is to assist in the liquid mixing, reaction, coating, printing, infusion and other process steps in the production process, avoiding the generation of bubbles and their impact on the final product. In many industrial and laboratory environments, removing bubbles is essential as they may have a negative impact on product quality, such as affecting surface tension and stability. Defoaming machines typically use various techniques such as vibration, ultrasound, centrifugation, etc. to achieve effective bubble removal. It has a wide range of applications, including but not limited to semiconductors, solar energy, optics, biotechnology, materials science, etc.

Technical Specification List

Full‑line standardized specifications for accurate process evaluation and equipment selection

Epoxy Coating TypeTypical StateRecommended Defoaming MethodRecommended Equipment
Color Matching / Sample PreparationSmall amount of coating materialCentrifugal / Vacuum DefoamingC Series / ZK Series
Epoxy Primer / TopcoatMedium-High ViscosityVacuum Stirring and DefoamingMIX60 / MIX80
Epoxy Floor Intermediate CoatHigh Viscosity High-buildVacuum Stirring and DefoamingMIX1000plus
High-filler Zinc-rich / High-build CoatingHigh Viscosity PasteVacuum stirring + Pressure Fine DefoamingMIX1000plus / RX Series

Multi‑Industry Solutions

Covering stirring and debubbling applications of typical materials across six major industries

Epoxy Flooring.jpg

Epoxy Flooring

Floor coating for factories, garages and workshops

Steel Structure Anti-corrosion.jpg

Steel Structure Anti-corrosion

Anti-corrosion coating for bridges, steel structures and facilities


Container

Anti-corrosion coating for containers and cabinets

Pipeline Anti-corrosion.jpg

Pipeline Anti-corrosion

Inner wall coating for oil & water pipelines and storage tanks

Marine Heavy Anti-corrosion.jpg

Marine Heavy-duty Anti-corrosion

Anti-corrosion coating for ship bottoms and ballast tanks

Coating Factory.jpg

Coating Factory

Production, color matching and filling of epoxy coatings

Comprehensive Equipment Operation Demo Videos

Gain intuitive, clear, dynamic insight into synchronous defoaming with planetary centrifugal force and high negative pressure.

Measured Defoaming‑Process Performance

Measured Processing Results for Six Typical Materials

Lubricant Stirring & Defoaming.jpg

Paste Materials

Photoresist Stirring & Defoaming.jpg

Adhesive with Powder

Polymer Materials.jpg

Polymer Materials

Pharmaceutical Gel Defoaming 02.jpg

Pharmaceutical Gel

Silver Paste Powder Stirring & Defoaming.jpg

Silver Paste Materials

Battery Slurry & Adhesive Stirring & Defoaming.jpg

Battery Slurry



Precautions for Use

NotesOperation Instructions
Accurate Mix RatioWeigh the two-component epoxy coating accurately before mixing and defoaming. Incorrect ratio will affect film formation.
Heating for Viscosity ReductionHeat high-viscosity high-build coating appropriately to reduce viscosity prior to defoaming to improve defoaming and leveling performance.
Standing Before CoatingAllow the material to stand for several minutes after defoaming before spraying / roller coating to reduce pinholes.
Slow Pressure ReliefRelease pressure slowly after defoaming to prevent re-foaming and splashing of coating material.

* Internal laboratory test data. Actual results vary with coating formulation and construction technology. Contact sales for real customer cases.

Customer Delivery & Application Cases

Rooted in manufacturing frontlines, empowering benchmark production lines and key national research institutions across diverse industries.



Stirring‑Defoaming Solution for Glue Materials in Consumer‑Electronics Industry



Vacuum Defoaming Solution for Consumer Electronics Adhesives



Industrial University Solves Bubble Challenges of Coating‑Film Materials with SIENOX Defoaming Machine
